1 Watt Slim (12vdc) Constant Current LED Module

Product Code: 1wLEDM-SL

£4.95 inc VAT (£4.12 ex VAT)

Stock Level: In-Stock

Select Colour
Quantity :
Quantity Prices:
5 for£4.75 each
10 for£4.50 each
20 for£4.25 each
View accessories for this product


Product Description

Our new slim 1 Watt LED Modules offer a bright light source with a wide beam in an extremely low profile package, and will outlast most other Modules on the market due to the protective internal electronics.

They are manufactured in a chain of 20 Modules but can be cut down to any number of modules required even a single module, the wire between the modules can also be easily extended if required to a few meters or several meters.

They have on-board Voltage and Current Regulating Electronics making them stable, highly reliable and suitable for use on 12vdc and even vehicle where voltages can reach 14.4 volts.

The electronics ensures that any increase in voltage does not result in an increased current to the LEDs resulting in a long lifetime with very little deterioration in brightness.

The on-board circuitry gives the Modules uniform brightness at all voltage levels.

Pre-fitted with Self-Adhesive Pads for fast installation, they also have a screw mounts on either side for securing in place in more harsh environments such as outdoors.

The Modules can be used with the Power Supplies listed below and can also be dimmed.

Available in White (5000k), Warm White (3500k), Blue, Green, and Red.

Product Specification

Voltage Range10-15vdc
Power1w
LED BrandEpistar with PLC Completion
Module Dimensions55mm (L) x 34mm (W) x 6.25mm (H)
Approx. Current Per Module143ma @ 12vdc)
DurabilityIP65
Wire Length between Module175mm
Length of a chain of 20 ModulesApprox 3.9M
CertificationsCE, RoHS
